13

Список деталей: рычажная таль

JLPА/B № № детали обозначение

размер кол-во

1 ......... JLP75-1 ............... Gear Case Assembly ................................. ................................ 1

........... Gear Case ............ ............................................................. ................................ 1

........... Bushing ............... ............................................................. ................................ 2

........... Cover Plate .......... ............................................................. ................................ 1

........... Rivet ................... 2x6 ........................................................ ................................ 2

2 ......... JLP75-2 ............... Spur Gear Assembly ................................. ................................ 2

........... Spur Gear ............ ............................................................. ................................ 2

........... Pinion Gear .......... ............................................................. ................................ 2

3 ......... JLP75-3 ............... Drive Shaft .............................................. ................................ 1

4 ......... JLP75-4 ............... Load Gear ............................................... ................................ 1

5 ......... JLP75-5 ............... Gear Side Plate Assembly .......................... ................................ 1

........... .......................... Gear Side Plate ........................................ ................................ 1

........... .......................... Stay Bolt ................................................ ................................ 3

........... .......................... Bushing .................................................. ................................ 2

........... .......................... Race "A" ................................................. ................................ 1

6 ......... JLP75-6 ............... Load Sheave ........................................... ................................ 1

8 ......... JLP75-8 ............... Guide Block ............................................. ................................ 1

9 ......... JLP75-9 ............... Guide Roller ............................................. ................................ 1

10 ....... JLP75-10 .............. Stripper .................................................. ................................ 1

11 ....... JLP75-11 .............. Roller Kit (34 rollers) ................................ 3x5 ........................... 1

12 ....... JLP75-12 .............. Bearing Race ........................................... ................................ 1

13 ....... JLP75-13 .............. Pawl Spring (1/2, 3/4T) ............................ ................................ 2

14 ....... JLP75-14 .............. Pawl ....................................................... ................................ 2

15 ....... JLP75-15 .............. Snap Ring (1/2, 3/4T) .............................. 8 .............................. 2

16 ....... JLP75-16 .............. Lever Side Plate Assembly ......................... ................................ 1

........... .......................... Lever Side Plate ....................................... ................................ 1

........... .......................... Race"B" .................................................. ................................ 1

........... .......................... Pawl Pin .................................................. ................................ 2

17 ....... JLP75-17 .............. Disc Hub ................................................. ................................ 1

18 ....... JLP75-18 .............. Spring (1/2, 3/4, 1-1/2T) .......................... ................................ 1

19 ....... JLP75-19 .............. Friction Disc ............................................ ................................ 2

20 ....... JLP75-20 .............. Ratchet Disc ............................................ ................................ 1

21 ....... JLP75-21 .............. Feed Gear ............................................... ................................ 1

22 ....... JLP75-22 .............. Brake Cover Assembly .............................. ................................ 1

........... .......................... Brake Cover ............................................ ................................ 1

........... .......................... Handle Case ............................................ ................................ 1

........... .......................... Nut ........................................................ ................................ 2

........... .......................... Bushing .................................................. ................................ 1

23 ....... JLP75-23 .............. Change Over Gear .................................... ................................ 1

24 ....... JLP75-24

.............. Lever Handle Assembly (1/2, 3/4T) ............ ................................ 1

........... .......................... Lever Handle ........................................... ................................ 1

........... .......................... Selector Lever ......................................... ................................ 1

........... .......................... Change Over Shaft ................................... ................................ 1

........... .......................... Cover ..................................................... ................................ 1

........... .......................... Rivet ...................................................... 3x12 ......................... 1

........... .......................... Bolt ........................................................ ................................ 2

........... .......................... Spring Seat ............................................. ................................ 1

........... .......................... Bushing .................................................. ................................ 1

24A ..... JLP75-24A ............ Rubber Grip ............................................ ................................ 1

25 ....... JLP75-25 .............. Change Over Pawl (1/2, 3/4T) ................... ................................ 1

26 ....... JLP75-26 .............. Spring Shaft (1/2, 3/4T) ........................... ................................ 1

27 ....... JLP75-27 .............. Spring (1/2, 3/4T).................................... ................................ 1

28 ....... JLP75-28 .............. Hand Wheel (1/2, 3/4T) ............................ ................................ 1

29 ....... JLP75-29 .............. Name Plate ............................................. ................................ 1

30 ....... JLP75-30 .............. Chain Stop (1/2, 3/4T) ............................. ................................ 1
