Western Digital NIC Conguration - 28 -

4-3 Adapter Board LEDs

LEDs on the Onyx bulkhead indicate various board state and activity.

•

• LEDs labeled “1” and “2” indicate Ethernet lane activity.

• The LED labeled ‘F’ indicates the rmware state.

• The LED labeled ‘H’ indicates hardware and management state.

4-3-1 Firmware State LED

The following table describes the meaning of the “F” or FW State LED. Please note that solid elds in this

table dene a solid (non-blinking) LED state.

LED: F

Stage

Controlled by

Amber

Boot sequence started

boot

Amber

This SPI ash device contains the rmware (FW)

that Fuji requires to run.

Green

*Recovery/Golden Image Booted – FW will Blink

the Amber LED while the Recovery Image is

running during normal operation

Amber

*Action Required (AR) Condition

Red

Reset button has been depressed

Green

Release Reset button to clear conguration

*Blink rate is once per second

NOTE!

• A sustained solid Amber indicates that the adapter must be shipped back to the factory (also known as a

“bricked” state.)

• This includes Power-On SelfTest (“POST”) failure.

• FW change to blinking Amber if Attention Required (“AR)”. Example causes:

• Booted to Golden RTL
