- 29 - Western Digital NIC Conguration
• Core Dumps in Flash
• Power-on Selftest (POST) Failure
• PCIe Link is up, not congured correctly
• Additional “attention” state where the user should access Fuji’s Management Interface for status
4-3-2 Reset EMP LED
The secondary Ethernet Management Port (EMP) and reset state are represented on a dual LED in the same
package. The reset function employs the green LED and the EMP employs the red LED. Combined they
appear to the user as amber.
LED: H Description
Controlled by
Off Board is off or in held in reset
Green Board is out of reset and there is no EMP activity
HW
Blink Green/yellow blink: EMP is active
EMP
