Continued from previous column

Power Connectors

∙ 1x 24-pin ATX main power connector

∙ 1x 8-pin +12V power connector

Internal USB

Connectors

∙ 1x USB 3.2 Gen 1 5Gbps connectors (From B760 chipset)

• Supports additional 2 USB 3.2 Gen 1 5Gbps ports

∙ 2x USB 2.0 Type-A connectors (From Hub-GL850G)

• Supports additional 4 USB 2.0 ports

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 2x 4-pin system fan connectors

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis intrusion connector

∙ 1x TPM module connector

∙ 1x Serial port connector

Jumpers ∙ 1x Clear CMOS jumper

LED Features

∙ 1x 4-pin RGB LED connector

∙ 2x 3-pin ARGB Gen2 LED connectors

∙ 4x EZ Debug LED

Back Panel

Connectors

∙ 1x HDMI™ port

∙ 1x PS/2 keyboard/ mouse port

∙ 2x USB 2.0 Type-A ports (From B760 chipset)

∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports (From B760 chipset)

∙ 1x 2.5Gbps LAN (RJ45) port

∙ 3x Audio jacks

I/O Controller NUVOTON NCT6687D Controller Chip

Hardware Monitor

∙ CPU/ System/ Chipset temperature detection

∙ CPU/ System fan speed detection

∙ CPU/ System fan speed control

Form Factor

∙ m-ATX Form Factor

∙ 8.7 in. x 9.6 in. (220 mm x 244 mm)

Continued on next column
