36 Specifications
BenQ FP783
+
Model
FP783
+
Display type
Viewable diagonal
Native (maximum) resolution
Colors
Contrast / Brightness
Response time
Viewing angle (left/right, up/down)
17.0" , active, TFT
43.2 cm
1,280X1,024
16.2 million
500:1 / 300 cd/m
2
8 ms
140, 130 (CR=10)
160, 160 (CR=5)
Line frequency
Image frequency
31.47 - 81.18 kHz Multi- frequency monitor
60 - 76 Hz modes within these parameters
Image checks
Controls
Functions
Digital, Screen OSD Technology, iKey
(automatic image setting)
5 buttons and iKey.
Contrast, brightness, vert. & hor. image position,
phase, pixel clock, color balance, color palette,
choice of language (8 language OSD), OSD posi-
tion, status indicator, input selection
Power Management
Max. power consumption
Power saving mode
VESA DPMS, EPA
60 Watt
< 3 Watt
Input signal
Synchronisation
RGB analog 0.7 Vpp/75 Ohm positive
Digital: DVI-D
TTL separate signal connection 15-pin mini D-sub
cable
Temperature (operating)
Air humidity (operating)
5 °C - 40 °C
20% - 80%
Certifications TCO 99, TÜV/Ergonomics, TÜV/ GS, FCC Class
B, ISO 13406-2, VCCI, UL, CB Report, CE,
C-Tick, BSMI, Fimko, GOST
Operating voltage
Dimensions (H x W x D)
Weight
100-240 V,
50-60 Hz
387 x 398 x 250 mm
5.2 kg
