Philips 32PFL3008K [5/10] Satellite installation

English - 4 -

Satellite installation

If you select Satellite option from the Search Type

screen, you can set a satellite and watch satellite

channels. When you select Satellite installation,

Antenna Type menu will be displayed.

There are three types of antenna selection. You can

select Antenna type as Direct, Unicable or DiSEqC

switch by using “

” or “ ” buttons.

Direct: If you have a single receiver and a direct

satellite dish, select this antenna type. After selecting

Direct, another menu screen will be displayed. Select

an available satellite by using cursor left or cursor

right, after your selection you have 2 possibilities

to continue installation, a full or a quick installation:

1. Press the green button and select “NO” followed

by “OK” to perform a full scan and search for all

available services on the selected satellite.

2. Press the green button and select “YES” followed

by “OK” to load a predened channel list and

confirm with (very quick installation, all main

services per country installed).

Unicable: If you have multiple receivers and an

unicable system, select this antenna type. Press OK to

continue. Congure settings by following instructions

on the screen. For full or quick installation follow the

instructions under “Direct”.

DiSEqC switch: If you have multiple satellite dishes

and a DiSEqC switch, select this antenna type. After

selecting DiSEqC switch, another menu screen will

be displayed. You can set four DiSEqC options (if

available). Press GREEN button to scan all satellites

or press YELLOW button to scan only the highlighted

satellite. To save and exit press OK button.

Play media les from a USB drive

You can play photo, music, and movie les stored on

a USB disk by connecting it to your TV. Connect

a USB disk to one of the USB inputs located

on the side of the TV. Pressing the “

” button

while in the Media Browser mode will access the

Picture, Sound and Settings menu options. Pressing the

“ ” button again will exit from this screen. You can

set your Media Browser preferences by using the

Settings Menu.

IMPORTANT! Back up your files before making

any connections to the TV. The manufacturer will

not be responsible for any file damage or data

loss. Certain types of USB devices, for example,

MP3 players or USB hard disk drives/memory

sticks may not be compatible with this TV.

Recording a program

Please format your USB ash drive / device before

rst use. To do this; press OK while Format Disk is

highlighted on screen and enter your pin number. The

factory default pin number is “0000”.

• To record a program, connect a USB ash drive

while your TV is turned off. Recording function will

be available once your TV is switched back on.

• The connected USB ash drives / devices must have

at least 1 gigabytes (1gb) of free space and USB 2.0

compatibility. An error message will be displayed if

these conditions are not met.

• By default, recorded programs are stored on the

connected USB ash drive / device. You may store

these programs on a computer as well, although you

can play them only on your TV.

• The TV supports FAT32 and NTFS disk formatting

but recording will not be available with NTFS

formatted disks.

Timeshift recording

Press PAUSE while watching a broadcast to activate

timeshifting mode.

• In timeshifting mode, the program is paused and

simultaneously recorded to the connected USB disk.

• Press

(PLAY) button again to resume the paused

program from where you stopped. Press the STOP

button to stop timeshift recording and return to the

live broadcast.

Note: Time shift cannot be used while in radio mode.

Media browser menu

Loop/Shufe Mode Operation

Start playback with

and activate

TV plays next le and loop the list.

Start playback with OK

and activate

File will be played in a loop (repeat).

Start playback with OK/

and activate

File will be played in a shufe.

Start playback with OK/

and activate

File playback will continue randomly and random playback will continue.
