Trap Settings

SNMP traps allow an SNMP agent to notify the NMS of a significant event. The switch supports two SNMP modes:

Trap mode and Inform mode.

SNMP Trap Mode—Trap

In Trap mode, the SNMP agent sends an SNMPv1 trap PDU to the NMS. No acknowledgment is sent back from

the NMS so the agent has no way of knowing if the trap reached the NMS.

SNMP Trap Mode—Inform

SNMPv2 provides an inform mechanism. When an inform message is sent from the SNMP agent to the NMS, the

receiver sends a response to the sender acknowledging receipt of the event. This behavior is similar to that of

the get and set requests. If the SNMP agent does not receive a response from the NMS for a period of time, the

agent will resend the trap to the NMS agent. The maximum timeout time is 300 sec (default is 1 sec), and the

maximum number of retries is 99 times (default is 1 time). When the SNMP agent receives acknowledgement

from the NMS, it will stop resending the inform messages.

Host IP Address 1

Setting Description Factory Default

IP or name Specifies the IP address or name of the primary trap server

used by your network.

None

1st Trap Community

Setting Description Factory Default

Max. of 30 characters Specifies the community string to use for authentication. Public

Host IP Address 2

Setting Description Factory Default

IP or name Specifies the IP address or name of the secondary trap server

used by your network.

None

2nd Trap Community

Setting Description Factory Default

Max. of 30 characters Specifies the community string to use for authentication. Public
