D-Link DWS-3024 [134/266] Viewing managed access point ethernet statistics

D-Link Unified Access System Software User Manual

02/15/2011

Page 134 Document 34CS3000-SWUM104-D10

On the WLAN Summary and Ethernet Summary pages, click the MAC address of the AP to view detailed statistics about

the AP.

Click Refresh to update the screen with the most current information.

Viewing Managed Access Point Ethernet Statistics

The Ethernet summary statistics show information about the number of packets and bytes transmitted and received on the

wired interface of each access point managed by the switch. The wired interface is physically connected to the LAN.

Table 38 describes the fields you see on the Ethernet Summary page for the managed access point statistics.

Click Refresh to update the screen with the most current information.

Viewing Detailed Managed Access Point Statistics

The detailed AP statistics show information about the packets and bytes transmitted and received on the wired and wireless

interface of a particular access point managed by the switch.

Table 37: Managed Access Point WLAN Summary Statistics

Field Description

MAC Address The Ethernet address of the Unified Switch managed AP.

Packets Received Total packets received by the AP on the wireless network.

Bytes Received Total bytes received by the AP on the wireless network.

Packets Transmitted Total packets transmitted by the AP on the wireless network.

Bytes Transmitted Total bytes transmitted by the AP on the wireless network.

Note: You can sort the list of APs by any of the column headings. For example, to sort the APs by the number of

packets transmitted, click Packets Transmitted.

Table 38: Managed Access Point Ethernet Summary Statistics

Field Description

MAC Address The Ethernet address of the Unified Switch managed AP.

Packets Received Total packets received by the AP on the wired network.

Bytes Received Total bytes received by the AP on the wired network.

Packets Transmitted Total packets transmitted by the AP on the wired network.

Bytes Transmitted Total bytes transmitted by the AP on the wired network.
