D-Link Unified Access System Software User Manual

02/15/2011

Page 148 Document 34CS3000-SWUM104-D10

Click Refresh to update the screen with the most current information.

The statistics on the Session Summary page show information about the traffic a wireless client receives and transmits

while it is connected to the same WLAN network shared by APs that the switch manages.

If the client roams from one AP to another AP but remains connected to the same network, the session continues and the

session statistics continue to accumulate. If the client closes the wireless connection or roams out of the range of an AP

managed by the switch, the session ends.

Click Refresh to update the screen with the most current information.

The statistics on the Association Detail page show information about the traffic a wireless client receives and transmits

while it is associated with a single AP.

Packets Received Packets received from the client station.

Bytes Received Bytes received from the client station.

Packets Transmitted Packets transmitted to the client station.

Bytes Transmitted Bytes transmitted to the client station.

Table 52: Associated Client Summary Statistics

Field Description

MAC Address The Ethernet address of client station.

Packets Received Packets received from the client station.

Bytes Received Total bytes received from the client station.

Packets Transmitted Total packets transmitted to the client station.

Bytes Transmitted Total bytes transmitted to the client station.

Table 53: Associated Client Association Detail Statistics

Field Description

MAC Address

(Menu)

Shows the MAC address of the client to which the values on the page apply.

To view details about a different associated client, select its MAC address

from the menu.

Packets Received Total packets received from the client station.

Bytes Received Total bytes received from the client station.

Packets Transmitted Total packets transmitted to the client station.

Bytes Transmitted Total bytes transmitted to the client station.

Fragments Received Total fragmented packets received from the client station.

Fragments Transmitted Total fragmented packets transmitted to the client station.

Transmit Retries Number of times transmits to client station succeeded after one or more

retries.

Transmit Retries Failed Number of times transmits to client station failed after one or more retries.

Table 51: Associated Client Association Summary Statistics

Field Description
