D-Link Unified Access System Software User Manual

02/15/2011

Page 166 Document 34CS3000-SWUM104-D10

Configuring Global Captive Portal Settings

Use the CP Global Configuration page to control the administrative state of the CP feature and configure global settings

that affect all captive portals configured on the switch. To configure the global CP settings, click Security > Captive Portal

> Global Configuration.

Figure 78: Global Captive Portal Configuration

Table 61 describes the global CP fields you can view or configure.

Use the buttons at the bottom of the page to perform the following tasks:

• Click Submit to update the switch with the values on the screen. If you want the switch to retain the new values across

a power cycle you must perform a save.

• Click Refresh to update the screen with the most current information.

Table 61: Global Captive Portal Configuration

Field Description

Enable Captive Portal Select the check box to enable the CP feature on the switch. Clear

the check box to disable the captive portal feature.

CP Global Operational Status Shows whether the CP feature is enabled.

CP Global Disable Reason If CP is disabled, this field displays the reason, which can be one

of the following:

• None

• Administratively Disabled

• No IPv4 Address

• Routing Enabled, But no IPv4 routing interface

Additional HTTP Port HTTP traffic uses port 80, but you can configure an additional CP

authentication server port for HTTP web connection. Enter a port

number between 0-65535 (excluding port 80, 443, and the

configured switch management port). The HTTP port default is 0

which denotes no additional port.

Authentication Timeout To access the network through a portal, the client must first enter

authentication information on an authentication Web page. Enter

the number of seconds to keep the authentication session open

with the client. When the timeout expires, the switch disconnects

any active TCP or SSL connection with the client. The range is 60-

600 seconds. The default is 300 seconds.
