39
Using BIOS
IGD Multi-Monitor (Disabled)
This item enables or disables IGD (Internal Graphics device) multi-monitor.
Press <Esc> to return to the Chipset Menu page.
f System Agent Configuration
Scroll to this item and press <Enter> and view the following screen:
The chipset menu items allow you to change the settings for the North Bridge
chipset, South Bridge chipset and other system.
Chipset Menu
System Agent (SA) Parameters
System Agent Configuration
PCH Configuration
f
f
f
ME Configuration
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
DVMT Memory (256M)
When set to Fixed Mode, the graphics driver will reserve a fixed position of the
system memory as graphics memory, according to system and graphics requirements.
IGD Memory (64M)
This item shows the information of the IGD (Internal Graphics Device) memory.
System Agent Configuration
IGD Memory [64M]
DVMT Memory [256M]
IGD Multi-Monitor [Disabled]
Select DVMT 5.0 Pre-Allocated
(Fixed) Graphics Memory size
used by the Internal Graphics
Device.
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced
Chipset M.I.B III Boot Security Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Main Advanced
Chipset M.I.B III Boot Security Exit
