ENGLISH
9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUX
Preparation:
Select [
ON
] for [
BUILT-IN AUX
]. (
4
)
Start listening
1
Connect a portable audio player (commercially available).
2 Press repeatedly to select AUX.
3 Turn on the portable audio player and start playback.
Set the AUX name
While listening to a portable audio player connected to the unit...
1 Press the volume knob to enter [
FUNCTION
].
2 Turn the volume knob to select [
SYSTEM
], then press the
knob.
3 Turn the volume knob to select [
AUX NAME SET
], then press the
knob.
4 Turn the volume knob to select an item, then press the
knob.
AUX
(default)/
DVD
/
PORTABLE
/
GAME
/
VIDEO
/
TV
5 Press and hold to exit.
To return to the previous setting item, press .
Auxiliary input jack
Portable audio player
3.5mm stereo mini plug with “L” shaped
connector (commercially available)
AUDIO SETTINGS
While listening to any source...
1 Press the volume knob to enter [
FUNCTION
].
2 Turn the volume knob to select [
AUDIO CONTROL
], then press the knob.
3 Turn the volume knob to select an item (see the following table), then
press the knob.
4 Repeat step 3 until the desired item is selected or activated.
5 Press and hold to exit.
To return to the previous setting item, press .
Default:
XX
SUB-W LEVEL –50
to
+10
(
0
): Adjusts the subwoofer output level.
MANUAL EQ
BAND1 LEVEL LEVEL
–9
to
+9
(
0
):(Refer to
BAND2 LEVEL
below.)
BASS EXTEND ON
:Turns on the extended bass.;
OFF
:Cancels.
BAND2 LEVEL
to
BAND13 LEVEL
–9
to
+9
(
0
): The sound elements (frequency level, tone level, Q factor) are
preset into each selection (
BAND1 LEVEL
to
BAND13 LEVEL
).
Adjusts the level to memorize for each source. (Before making an adjustment,
select the source you want to adjust.)
Q FACTOR 1.35
/
1.50
/
2.00
:Adjust the quality factor.
PRESET EQ NATURAL
/
ROCK
/
POPS
/
EASY
/
TOP40
/
JAZZ
/
POWERFUL
/
USER
: Selects a
preset equalizer suitable to the music genre. (Select [
USER
] to use the settings
made in [
MANUAL EQ
].)
BASS BOOST LEVEL1
/
LEVEL2
/
LEVEL3
/
LEVEL4
/
LEVEL5
:Selects your preferred bass boost
level.;
OFF
:Cancels.
LOUDNESS LEVEL1
/
LEVEL2
:Selects your preferred low and high frequencies boost to
produce a well-balanced sound at a low volume level.;
OFF
:Cancels.
SUBWOOFER SET ON
:Turns on the subwoofer output.;
OFF
:Cancels.
JS_KWD_KDC_300UV_EN_EN_7.indd 9JS_KWD_KDC_300UV_EN_EN_7.indd 9 5/10/2015 4:01:57 PM5/10/2015 4:01:57 PM
