7-29
25/30 2006
7
6. Put ass'y of tilt cylinder 1, tilt rod 4, inner tube 8, free
piston 6 and O-ring in the PTT unit 9.
9
1
8
4
6
271271
LT
271
ATFATF
OIL
ATF
ATFATF
OIL
ATF
1
Tilt Cylinder End screw 1 :
155 N·m ( 112 lb·ft ) [ 15.5 kgf·m ]
w
4
7. Install tilt cylinder 1 and tighten to specified torque.
9. Add PTT fluid to specified level with tilt rod 4 fully stretched.
8. Put nut 0 and joint q on the tilt rod ass'y 4, and tighten to
specified torque.
Joint Nut Tilt Rod :
35 N·m ( 18 lb·ft ) [ 3.5 kgf·m ]
1
9
0
q
271271
LT
271
5. Add PTT fluid to the first step of bottom of tilt cylinder
installation hole.
Reserve Tank Cap :
1.5 N·m ( 1.1 lb·ft ) [ 0.15 kgf·m ]
10. Put cap w and tighten to specified torque.
Recommended PTT Fluid :
ATF DEXRON III
OIL
Recommended PTT Fluid :
ATF DEXRON III
OIL
