Tohatsu MFS 30 [33/319] Specifications
![Tohatsu MFS 30 [33/319] Specifications](/views2/1240939/page33/bg21.png)
2-7
2
25/30 2006
5.Specifications
Item Unit
MF EF EP EFT EPTMFG EFG EPG
Outboard Model
Dimensions (approx.)
Overall Length mm (in) 1,031 (40.59)
652 (25.67)
1,031 (40.59)
652 (25.67)
1031 (40.59)
652 (25.67)
Overall Width mm (in) 391 (15.39)
367 (14.45)
391 (15.39)
367 (14.45) 391 (15.39) 367 (14.45)
Overall Height S mm (in) 1,187 (46.73)
L mm (in) 1,335 (52.56)
UL mm (in) 1,462 (57.56)
Transom Length S mm (in) 404 (15.91)
L mm (in) 552 (21.73)
UL mm (in) 679 (26.73)
Weight (approx.)
S kg (lb)
71.5 (157.6) 74.5 (164.2)
73 (160.9) 78 (172.0) 81 (178.6)
79.5 (175.3) 82.5 (181.9)
81 (178.6)
L kg (lb)
73 (160.9) 76 (167.5)
74.5 (164.2) 79.5 (175.3) 82.5 (181.9)
81 (178.6) 84 (185.2)
82.5 (181.9)
UL kg (lb)
75 (165.3) 78 (172.0)
76.5 (168.7) 81.5 (179.7) 84.5 (186.3)
83 (183.0) 86 (189.6)
84.5 (186.3)
Performance
Maximum Output kW (ps) 25 : 18.4 (25) 30 : 22.1 (30)
Full-throttle revolution
speed range
r/min 25 : 5,000 to 6,000 30 : 5,250 to 6,250
Full-throttle Fuel Consumption
L/hr 25 : 8.8 30 : 10.4
Idling (Neutral [N]) r/min 850 ±30
Trolling (Forward [F]) r/min 850 ±30
Power Unit
Engine Type 4 Stroke Gasoline Engine
No. of Cylinders 3
Piston Displacement cm
3
(cu in) 526 (32.09)
Valve System SOHC
Bore x Stroke mm (in) 61 x 60 (2.402 x 2.362)
Compression Ratio 9.4
Shift Operation System
Starting System
Lubrication System Wet Sump
Cooling System Water Cooling (Impeller System)
Exhaust System Through-the-prop Exhaust
Ignition System CD Ignition
Range of Ignition Augle
TDC 0° to BTDC 38° (ECU timing control)
Spark Plugs DCPR6E [NGK]
Alternator Output 12V–15A
Fuel Feed System Electronic Fuel Injection
Front Shift
(Manual)
Front Shift
(Manual)
Remote
Control
Recoil
Starting
Recoil
Starting
Recoil/Electric
Starting
Recoil/Electric Starting
Remote
Control
Front Shift
(Manual)
Remote
Control
