2-9
2
25/30 2006
14 (3 x 9 x 14) (3 x 252 x 360)
DS13 (3 x 10 x 13) (3 x 257 x 330)
DS12 (3 x 9 x 12) (3 x 252 x 305)
Marking DS11 (3 x 9 x 11) in (3 x 252 x 279) mm
DS10 (3 x 9 x 10) (3 x 252 x 254)
DS9 (3 x 9 x 9) (3 x 252 x 229)
8 (3 x 10 x 8) (3 x 260 x 210)
Tachometer No. of Poles 12
Remote Control Cable
Feet Cable Length : 7 - 30 feet
Propeller [Marking]
(No. of Blades x
Diameter x Pitch)
[in/mm]
7
8
7
8
7
8
7
8
8
1
4
1
Item Unit
MF EF EP
Outboard Model
MFG EFG EPG
*1 Stop engine to cancel warning system operation.
Water Temperature MAP
Sensor Malfunction
7
8
EFT EPT
Over-revolution
Protection
Controls engine speed to approximately 6,300 r/min or
less. Warning buzzer sounds, and warning lamp is lit.
Warning System
Optional Parts
Engine Hydraulic
Pressure Low
Engine Cooling Water
Temperature Abnormally High.
Warning System
Operation Check
*1
*1
Controls engine speed to approximately 2,800 r/min or
less (Low Speed ESG). Warning buzzer sounds, and warning lamp is lit.
Controls engine speed to approximately 2,800 r/min or
less (Low Speed ESG). Warning buzzer sounds, and warning lamp is lit.
Controls engine speed to approximately 2,800 r/min or
less (Low Speed ESG). Warning buzzer sounds, and warning lamp blinks
Warning buzzers sounds for 2 seconds and lamp is lit for 5 seconds.
