Mitsubishi Electric SEZ-KD50VAQ / SUZ-KA50VA [17/34] Installation relocation and inspection
![Mitsubishi Electric SEZ-KD50VAQ / SUZ-KA50VA [17/34] Installation relocation and inspection](/views2/1324275/page17/bg11.png)
17
Also consider operation sound
• Do not put an object around the air outlet of the outdoor unit. It may cause lowering of capacity or increase operating sound.
• If abnormal sound is heard during operation, consult your dealer.
Relocation
• When the air conditioner is to be removed or reinstalled because of rebuilding, moving, etc., special techniques and work are required.
Warning:
Repair or relocation should not be done by the customer.
If this is done incorrectly, it may cause a fire, electric shock, injury by dropping of the unit, water leakage, etc. Consult your dealer.
Disposal
• To dispose of this product, consult your dealer.
If you have any question, consult your dealer.
11. Installation, relocation and inspection
12. Specifications
Notes: 1. Specifications subject to change without notice.
2. The external static pressure is set to 15 Pa at factory shipment.
Guaranteed operating range
Indoor
Outdoor
SUZ-KA25, 35VA
SUZ-KA50, 60, 71VA
SUZ-KA·NA
Cooling
Upper limit 32°C DB, 23°C WB 46°C DB, – 43°C DB, –
Lower limit 21°C DB, 15°C WB -10°C DB, – 18°C DB, –
Heating
Upper limit 27°C DB, – 24°C DB, 18°C WB
Lower limit 20°C DB, – -10°C DB, -11°C WB
Units should be installed by licensed electric contractor accordingly to local code requirement.
SEZ-KD35VA
0.05
0.46
7-9-11
5/15/35/50
23-28-33
200×990×700
21
SEZ-KD71VA
0.10
0.84
12-16-20
5/15/35/50
30-35-40
200×1190×700
27
Model
Power supply
Input (Indoor only) kW
Current (Indoor only) A
Airflow (Lo-Mid-Hi) CMM
Ext. static pressure Pa
Noise level (Lo-Mid-Hi) dB
Dimension (H×W×D) mm
Weight kg
SEZ-KD50VA
0.07
0.63
10-12.5-15
5/15/35/50
30-34-37
200×990×700
23
SEZ-KD60VA
0.07
0.63
12-15-18
5/15/35/50
30-34-38
200×1190×700
27
SEZ-KD25VA
0.04
0.39
5.5-7-9
5/15/35/50
23-26-30
200×790×700
18
~/N, 230V, 50Hz/220-230V, 60Hz
KB79H133H04_en.pm6 08.6.24, 11:39 AM17
