f Wear safety goggles.
f Danger area! Keep hands, fingers or arms away from this
area.
Only for EC countries:
Do not dispose of power tools into household waste!
According the European Guideline 2002/96/EC for Waste Elec-
trical and Electronic Equipment and its implementation into na-
tional right, power tools that are no longer usable must be col-
lected separately and disposed of in an environmentally correct
manner.
Indicates the rotation direction of the handwheel for lowering
(transport position) and raising (working position) the saw
blade.
Carry out the adjustment of the bevel angle (= vertical mitre an-
gle) (saw blade can be tilted) in the indicated sequence.
Indicates the maximum permissible workpiece height for the
standard bevel angles 90° and 45°.
Symbol Meaning
1.
4.
3.
2.
Push
90°
45°
75 mm
63 mm
