13-2. Indoor Unit (Part-E)

Location Part Location Part

No. No. No. No.

401 43T69319

406 43T6V756

402 43T6V673 406

43T6V757

403 43T6V674 406

43T6V758

404 43T62340

TEMPERATURE SENSOR

TERMINAL(5P-TF)

TEMPERATURE SENSOR

CORD-CLAMP

406 43T6V759

Description Description

405

43T6V681

PC BOARD ASSY:WRS-LED

406

43T6V760

PC BOARD(FOR RAS-05BKVG-E)

PC BOARD(FOR RAS-07BKVG-E)

PC BOARD(FOR RAS-10BKVG-E)

PC BOARD(FOR RAS-13BKVG-E)

PC BOARD(FOR RAS-16BKVG-E)

FILE NO. SVM-16030

- 120 -
