Getting started
8
Getting star ted
Do not connect the QL-500/560 to your personal computer until directed to do so
when installing the printer driver.
Use CUT lever when cutting a printed label.
Front
QL-500
QL-560
Rear
QL-500 / QL-560
1 Parts Description
Main Printing Unit
FEED button
LED lamp
ON/OFF button
CUT lever
DK Roll compartment cover
FEED button
LED lamp
ON/OFF button
CUT button
DK Roll compartment cover
Power cord
USB port
CUT Lever
