Thank you for purchasing the QL-500/560.
This guide briefly describes the steps to start using your QL-500/560.
Refer to the Software User's Guide for more detailed information. The Software User's
Guide can be found in the Manuals folder of the CD-ROM included with the QL-500/560.
We strongly recommend that you read this manual carefully before using your QL-500/560,
and then keep it nearby for future reference.
We provide service & support for users who register their products on our website.
We recommend that you take this opportunity to register with us by visiting us at:
Online Support Page
support.brother.com
NOTE: It is also possible to access the above sites from the online user registration
window of the CD-ROM installer disk which is included with the printer. We look
forward to your registration.
Declaration of Conformity
(Europe/Turkey only)
We, Brother Industries, Ltd.
15-1, Naeshiro-cho, Mizuho-ku,
Nagoya 467-8561 Japan
declare that this product is in conformity with the essential requirements of all relevant directives and
regulations applied within the European Community.
The Declaration of Conformity (DoC) can be downloaded from our website. Visit support.brother.com
and:
• select "Europe"
• select your country
• select "Manuals"
• select your model
• select "Declaration of Conformity"
• click "Download"
Your Declaration will be downloaded as a PDF file.
