Brother PJ-673 [26/75] Setting up the printer with the default settings changed
![Brother PJ-673 [26/75] Setting up the printer with the default settings changed](/views2/1471110/page26/bg1a.png)
Chapter 1
22
k Windows
®
8 / Windows
®
7:
Click [Next].
Windows Vista
®
/ Windows
®
XP:
Click [Next].
When the completion screen for the
[Add Printer Wizard] appears, click
[Finish] to close the screen.
NOTE
Then, follow the on-screen instructions to
finish adding the printer. If a screen for
selecting printer sharing appears, select
“No share”.
l Use any application to check that
printing can be performed with this
printer.
If printing does not work
If the printer is turned off, the wireless LAN
connection will be ended. Even if the
printer is turned on, printing will not be
possible until the connection is
re-established.
Turn on the printer, hold down the
(Power) button for at least 3 seconds
to enter wireless LAN mode, and then
re-establish the connection after setting
up the computer running Windows
®
(page 17 or page 24).
Setting Up the Printer
(With the Default Settings Changed)
1
NOTE
• Since a USB cable is required to change
the printer’s default settings, prepare one.
In the process, the printer driver for a
USB connection will be installed on
the computer running Windows
®
.
• In order to use the printer via a wireless
LAN connection, settings must be
specified on both the printer and the
computer running Windows
®
. The printer
settings will be specified with the printer
driver; however, the settings on the
computer running Windows
®
must be
specified manually. Specify the settings
according to the procedures in this
manual.
a If you have the included CD-ROM, insert
it into your computer’s CD-ROM drive,
and then click [Standard Installation]
in the installer screen that appeared.
If the Web version was downloaded,
double-click the downloaded file.
Click [Next].
