20
H. / Threading mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA3250001 1
A
RM THREAD GUIDE,
A
2 062500616 4 SCREW PAN M5X6
3 SA4333001 1
A
RM THREAD GUIDE,B
4 SA6391001 1
A
RM THREAD GUIDE C
5 SB1086001 1
A
RM THREAD GUIDE D
6+ P.53 1
THREAD TAKE-UP SPRING
7 SB1084001 1
DT TENSION STUD
8 SB1088001 1 SET COLLAR DT
9 SB1180001 1
SHAFT
10 SB1181001 1 DT CUSHION
11 SA6190001 1 DISC DT
12 SB1267001 1
COIL SPRING
13 145446001 1 DISC, TENSION
14 SB1281001 1 TAPER DISC PRESSE
R
15 018301036 1
BOLT SOCKET M3X10
16 SB1182001 1
TENSION BRACKET ASS
Y
17 012400436 1 SET SCREW SOCKET (FT) M4X4
18 021500316 1 NUT 3 M5
19 153484001 1
WASHER, PLAIN 4.76
20 SA4143001 1
SET SCREW, (FT) M6X6
21 SA3256001 1
TENSION STUD
A
22 100136001 1 TENSION NUT
23 SA4146101 1
SUB TENSION SPRING
24 145446001 2 DISC, TENSION
25 SB1087001 1 THREAD GUIDE ARM
26 021400306 1 NUT 3 M4
27 SB1058001 1
N-BAR BUSH THREAD GUIDE D
28 SB1085001 1
TENSION RELEASE PIN
29+ P.54 1
NEEDLE BAR THREAD GUIDE
<OPTION PARTS>
30 152881101 1 NEEDLE COOLER ASS
Y
31 012060636 1 SET SCREW SOCKET (FT) M6X6
32 152883000 1 FELT, 8X15.5
33 152884001 1 NEEDLE COOLER THREAD GUIDE
34 062670412 1 SCREW PAN SM3.57-40X4
KE-430F/BE-438F-401
20
