32
K. / Looper mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA6828001 1
LOOPER LEVER SHAFT
2 014500836 2
SET SCREW SOCKET (CP) M5X8
4 SA6829001 1
LOOPER LEVER ASSY
5 SA6830001 1
LOOPER LEVER
6 SA6831001 2
SHAFT 6.35
7 012500536 2 SET SCREW SOCKET (FT) M5X5
8 SA6834001 1 LOOPER DRIVING PLATE
9 SA6835001 1 WICK 2X2
10 SA6836001 1 WICK 2X2
11 SA5565001 1
OIL TUBE
12 SA6837001 1
LOOPER TUBE CLAMP A
13 060300816 1
SCREW BIND M3X8
14 SA6838001 1 WICK 3X3
15 SA6839001 1
OIL TUBE
16 SA6840001 1
LOOPER TUBE CLAMP B
17 060300816 1
SCREW BIND M3X8
18 SA6832001 1
LOWER SHAFT CAM COLLER
19 SA6833001 1
LOOPER CAM ROLLER SHAFT
20 S12718000 1 CHEMICAL FELT
21 014060632 1
SET SCREW SOCKET (CP) M6X6
RH-9820-306
32
