Brother RH-9820-01/02 [41/118] L double chain stitch looper m echanism
![Brother RH-9820-01/02 [41/118] L double chain stitch looper m echanism](/views2/1497396/page41/bg29.png)
36
L. / Double chain stitch loo
p
er mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
55 S35035101 1
SPRING, TWIST :R
56 S35036101 1
SPRING, TWIST :L
57 SA6872001 1 NEEDLE GUARD U
58 018300836 1
BOLT SOCKET M3X8
59 025030136 1
WASHER PLAIN S 3
<For -00>
60 SA7063001 1 GIMP THREAD GUIDE C
<For -01>
61 SA7578001 1 GIMP THREAD GUIDE C ASSY
60 SA7063001 1 GIMP THREAD GUIDE C
63 SA7613001 1 GIMP THREAD CLAMP PLATE
64 SA7614001 1
GIMP THREAD TENSION SPRING
65 062300506 1 SCREW PAN M3X5
66 025030236 1
WASHER PLAIN M 3
67 SA7615001 1 COLLAR 3
<For -02>
68 SA6873001 1 GIMP THREAD GUIDE C-J ASSY
62 SA6874001 1 GIMP THREAD GUIDE C-J
63 SA7613001 1 GIMP THREAD CLAMP PLATE
64 SA7614001 1
GIMP THREAD TENSION SPRING
65 062300506 1 SCREW PAN M3X5
66 025030236 1
WASHER PLAIN M 3
67 SA7615001 1 COLLAR 3
69 060400516 1
SCREW BIND M4X5
<For -00 & -01>
70 SA7065001 1
THROAT PLATE 1.6
<For -02>
70 S37752001 1
THROAT PLATE, 1.8-J
71 S35326101 1
SCREW M3.5
72 SA6875001 1
VERTICAL PIN
73 014300832 1
SET SCREW SOCKET (CP) M3X8
74 SA6876001 1 THREAD GUIDE PLATE
75 SA6877001 1 COLLAR
76 SA6878001 1
L TR TAKE-UP SPRING SUPPORT
77 062402016 1 SCREW PAN M4X20
78 SA6879001 1
SPRING GUIDE SHAFT
79 021400316 1 NUT 3 M4
80 SA6880001 1
THREAD TAKE-UP SPRING
81 SA6881001 2
L TR TAKE-UP SPRING SUPPORT
82 060300816 1
SCREW BIND M3X8
83 0A4300805 1
SCREW PAN (S/P WASHER) M3X8
<For -02>
84 060300816 1
SCREW BIND M3X8
85 S37725001 1
COMPRESSIONSPRING
91 SA6868001 1 LOWER THREAD PRESSER J ASSY
<Option parts>
86 SA7634101 1 EYE LOOPER, B
87 S49078001 1 LOOPER, L-S
88 S35472101 1
SPREADER, LB
89 S49079001 1
SPREADER, L-S
90 SA7546001 1
THROAT PLATE, 1.1
RH-9820-309
36
