Brother RH-9820-01/02 [45/118] N lubrication
![Brother RH-9820-01/02 [45/118] N lubrication](/views2/1497396/page45/bg2d.png)
40
N. / Lubrication
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA6893001 1 OIL PLATE ASSY
4 S35001000 8 NYLON RIVET
5 SA6896001 1
OIL TUBE
6 SA6897001 1 WICK 3X3
7 SA6898001 1 WICK 3X3
8 SA6899001 1 WICK 6X6
9 S00480000 1
CORD HOLDER, 5N
10 0A4400806 1
SCREW PAN (S/P WASHER) M4X8
11 062400816 4 SCREW PAN M4X8
12 SA6900001 1
OIL TUBE
13 SA6901001 1 WICK 2X2
14 146202000 1
CORD HOLDER, 6N
15 0A4400806 1
SCREW PAN (S/P WASHER) M4X8
16 S10243000 1
CORD HOLDER, NK-3N
17 0A4400806 1
SCREW PAN (S/P WASHER) M4X8
18 149547000 1 CORD HOLDER, 4N
19 0A4400806 1
SCREW PAN (S/P WASHER) M4X8
20 SA6902001 1
TUBE SUPPORT
21 018400636 2
BOLT SOCKET M4X6
22 S10243000 1
CORD HOLDER, NK-3N
23 0A4400806 1
SCREW PAN (S/P WASHER) M4X8
24 SA6903001 1
OIL STOPPER
25 SA6904001 1 FELT HOLDER ASSY
27 SA6906001 2
N-BAR YOKE FELT
28 SA6907001 1 SLIDE BLOCK FELT D
29 SA6908001 1 WICK 2X2
30 S35001000 1 NYLON RIVET
31 018400636 2
BOLT SOCKET M4X6
32 SA6909001 1
OIL TUBE
33 SA6910001 1 WICK 2X2
34 S56911000 1
OIL JOINT S
35 S51020000 1 COLLAR
36 S10243000 2
CORD HOLDER, NK-3N
37 0A4400806 2
SCREW PAN (S/P WASHER) M4X8
38 SA6911001 1
OIL PLATE
39 062400616 2 SCREW PAN M4X6
40 S49992000 1
OIL GAUGE WINDOW
41 S00480000 2
CORD HOLDER, 5N
42 552907000 2
CORD HOLDER #10
43 0A4400806 4
SCREW PAN (S/P WASHER) M4X8
44 SA6912001 2 WICK 2X2
45 SA6913001 1 WICK 2X2
46 S29700000 4 FELT
47 153050000 1 S-RACE BASE FELT
48 SA6914001 1 WICK 2X2
49 S29700000 6 FELT
50 SA6915001 1 FELT ASSY
51 SA6918001 1
OIL TUBE
52 SA6919001 1
TUBE GUIDE
53 018400836 1
BOLT SOCKET M4X8
54 S25328001 1 FELT
56 SA6921001 1
SUB-TANK ASSY
57 SA3040001 1 OIL FEEDING PIPE
58 SA3060001 1
VALVE PACKING
59 SA6922001 1 OIL CONNECROR 6.5-3.8
60 104450101 1
RUBBER CAP, 8
61 SA6923001 1
OIL TUBE
62 SA6924001 1 WICK 6X6
63 SA6925001 1
OIL TUBE
64 SA6926001 1 WICK 3X3
65 SA6927001 1
OIL TUBE
66 SA6928001 1 WICK 6X6
67 SA6929001 1
TUBE CLIP SPRING
RH-9820-350
40
