W. / Operation panel mechanism
REF.NO CODE Q'TY NAME OF PARTS RM
1 SA6547001 1 OPERATION PANEL ASSY
2 SA6550001 1 PANEL SHEET
3 SA5148001 1
PCB ASSY PANEL
4 SA5360001 1
LIGHT PLATE ASSY
5 SA6546001 1 PANEL HARNESS
6 0B0452006 4 WOOD SCREW ROUND M4.5X20
7 J03974001 1
LAMP HOLDER
8 J04146001 1 DIFFUSION SHEET 75PBA
RH-9820-530
