Brother RH-9820-01/02 [93/118] Aa4 attachm ent set
![Brother RH-9820-01/02 [93/118] Aa4 attachm ent set](/views2/1497396/page93/bg5d.png)
88
AA4. / Attachment set
REF.NO CODE Q'TY NAME OF PARTS RM
62 542515001 2
SCREW M2.6X3.5
63 S34887001 1
SPRING, PLATE ;F-KNIFE
64 S34886001 1
SPRING, U PLATE ;F-KNIFE
65 SA7077001 1
PRESSER PLATE U
66 060400516 2
SCREW BIND M4X5
67 152904001 1
SCREW, SM4.37
68 104336003 1
SCREW, SM2.38
69 S34884000 1
OPENER SPRING
70 060630312 2
SCREW BIND SM2.38-56X3
71 021400306 1 NUT 3 M4
72 062300416 2 SCREW PAN M3X4
73 SA7060001 1
WORK CLAMP PLATE LS30 UNIT
74 SA7061001 1
WORK CLAMP PLATE LS ASSY
75 S35315001 1 OPENING SLIDE BLOCK
76 S35316001 1 SLIDE BLOCK SUPPORT PLATE
77 060020416 2
SCREW BIND M2X4
78 SA5672001 1 NEEDLE PLATE L-42
79 S06696004 2
SCREW, FLAT M3X6
80 S39931101 1 CLOTH WORK CLAMP, L-30
81 S35236000 1
WASHER, BENDING 3.2
82 S35235001 1
SUPPORT PIN, CLAMP
83 021300306 1 NUT 3 M3
84 SA5560001 1
CLAMP SHAFT HOLDER
85 062400816 2 SCREW PAN M4X8
86 SA5674001 1
CLAMP FULCRUM SHAFT
87 048060142 2
RETAINING RING EXTERNAL C6
88 SA5671001 1
CLAMP LEVER L
89 018501236 1
BOLT SOCKET M5X12
90 SA5577001 1
CLAMP ARM L
91 014400536 2
SET SCREW SOCKET(CP) M4X5
92 SA7551001 1
CROTH GUIDE L
93 S35326101 1
SCREW M3.5
94 S35329001 1
WORK CLAMP PLATE, L
95 SA7783001 1 EXCHANGE PARTS SET 01
96 SA7578001 1 GIMP THREAD GUIDE C ASSY
97 SA7063001 1 GIMP THREAD GUIDE C
98 SA7613001 1 GIMP THREAD CLAMP PLATE
99 SA7614001 1
GIMP THREAD TENSION SPRING
100 062300506 1 SCREW PAN M3X5
101 025030236 1
WASHER PLAIN M 3
102 SA7615001 1 COLLAR 3
103 SA7064001 1
UPPER MOVABLE KNIFE
104 060300416 1
SCREW BIND M3X4
105 S35029001 1 UPPER MOVABLE KNIFE, A
106 SA7065001 1
THROAT PLATE 1.6
107 SA6971001 1
L-THREAD TAKE-UP GUIDE LENER
108 SA6974001 1 LOWER THREAD GUIDE C
109 SA7068001 1
GIMP THREAD TAKE-UP G-L ASSY
110 SA7069001 1
GIMP THREAD TAKE-UP G-HOLDER
111 SA7070001 1 G-THREAD TAKE-UP GUIDE PLATE
112 SA7071001 1 GIMP THREAD TAKE-UP G-E PLATE
113 SA7072001 1
SHOULDER SCREW M4
114 021400306 1 NUT 3 M4
115 158722001 1
WASHER PLAIN 4.2
116 SA7073001 1 GIMP THREAD GUIDE
117 062300416 1 SCREW PAN M3X4
118 SA7074001 2
SPRING TORSION
120 SA7053001 1 G-THREAD TAKE-UP GUIDE COLLER
121 SA7054001 1
G-THREAD TAKE-UP GUIDE SHAFT
122 048050142 1
RETAINING RING EXTERNAL C5
123 014400536 1
SET SCREW SOCKET(CP) M4X5
RH-9820-940
88
