Sven MS-1095 [16/20] Computer speaker system

you want - we can

ENG

Computer Speaker System

Fig.1. Rear panel

5. PREPARATION AND OPERATION

Speaker placement

• Place the satellites symmetrically to

the listener at the distance not less than

one meter.

• Place MSS far away from monitors

and TV sets, as insignificant image dis-

tortion in these supersensitive devices

is possible. We recommend that the

subwoofer should be placed on the

table.

Installation and operation guide

MS-10 95 Multimedia Speaker System can be

connected to virtually any audio source: DVD/

CD/ MP3, TV, PC sound card, etc. (see Fig. 2).

WARNING! All the components should be switched off before connection.

• Connect the subwoofer and the satellites (see Fig. 2).

• Plug the mini-jack of the signal cable (2RCA to mini-jack) into

Line out port of the computer sound card

or an audio output of your CD/MP3 player, then insert the 2RCA-jacks of the signal cable into the sub-

woofer input connector OUTPUT d. Note that the white RCA-jack must be connected to the white sub-

woofer terminal and the red RCA-jack – to the red subwoofer terminal.

• Plug the mini-jack of the microphone cable into the Mic jack of the computer sound card, then insert

the other mini-jack of the microphone cable into the MIC microphone output a.

• Plug the headset into jacks 7 and 8 on the wired remote control.

Note. To connect the MSS to a DVD player or TV, use a 2RCA to 2RCA signal cable (not included),

as shown in Fig. 2.

• Plug the power cord i into a mains outlet.

• Set the volume control knob f to its minimum by turning knob f counter-clockwise until it stops,

switch on the device with POWER e switch on the subwoofer rear panel.

• Set the required volume with the volume control knob on the wired remote control.

• Keep the subwoofer volume control knob in mid position.

Notes:

• If the MSS is left unused for a long period of time, please mind to switch off POWER e on the

subwoofer rear panel and unplug it.

• To improve the sound quality, use the Line-Out port of your sound card.

a b

c d

f Volume control knob

g : headphone jack

h : microphone jack

i Power cord

230V ~50 Hz
