Gigabyte MZ32-AR0 (rev. 1.0) [99/146] 3 5 5 i2c configuration options

- 99 - BIOS Setup

2-3-5-5 I2C Conguration Options

Parameter

Description

I2CCongurationOptions

I2C #0 #1 #2 #3 #4 #5

Enable

Enable/Disable the I2C function.

Options available: Auto, Enabled, Disabled. Default setting is Auto.
