- 51 - BIOS Setup

2-2-3 Network Stack

Network stack

Enable/Disable UEFI network stack.

Options available: Enabled/DIsabled. Default setting is Disabled.

Ipv4 PXE Support

(Note)

Enable/Disable Ipv4 PXE feature.

Options available: Enabled/DIsabled. Default setting is Enabled.

Ipv6 PXE Support

(Note)

Enable/Disable Ipv6 PXE feature.

Options available: Enabled/DIsabled. Default setting is Enabled.

PXE boot wait time

(Note)

Press <+> / <-> keys to increase or decrease the desired values.

Media detect time

(Note)

Press <+> / <-> keys to increase or decrease the desired values.

(Note) This item appears when Network Stack is set to Enabled.
