- 51 - System Hardware Installation

Top Middle Board to HDD Back Plane Board Cable (NVMe/Node1)

Bottom Middle Board to HDD Back Plane Board Cable (NVMe/Node2)

N1 U.2 A

N1 U.2 B

N2 U.2 A

N2 U.1BA
