- 59 - BIOS Setup
Parameter Description
Boot Conguration
Setup Prompt Timeout
Number of seconds to wait for setup activation key. 65535 (0xFFFF)
means indenite waiting.
Press the numeric keys to input the desired values.
Bootup NumLock State
Enable/Disable the Bootup NumLock function.
Options available: On/Off. Default setting is On.
Quiet Boot
Enable/Disable showing the logo during POST.
Options available: Enabled/Disabled. Default setting is Enabled.
FIXED BOOT ORDER
Priorities
Boot Option #1 / #2 / #3 / #4 /
#5
Press [Enter] to congure the boot priority.
By default, the server searches for boot devices in the following
sequence:
1. Hard drive.
2. CD-COM/DVD drive.
3. USB device.
4. Network.
5. UEFI.
UEFI sUEFI Application Boot
Priorities
Press [Enter] to congure the boot priority.
UEFI Network Drive BBS
Prioritie
Press [Enter] to congure the boot priority.
