Zkteco TL100 [15/17] Mark and drill holes for strike
![Zkteco TL100 [15/17] Mark and drill holes for strike](/views2/1703549/page15/bgf.png)
14
7. Mark and drill holes for strike
F
261 mm
177 mm
80.5 mm
31 mm
33 mm
22.2 mm
12 mm
34.6 mm
42 mm
24 mm
18 mm
2 mm
1.2 mm
G
H
F
