M-Audio UC-33e [6/22] Programming editing the uc 33
![M-Audio UC-33e [6/22] Programming editing the uc 33](/views2/1790358/page6/bg6.png)
6
Programming & Editing The UC-33
Introduction To UC-33 Programming Options
Each of the UC-33’s 47 controllers can send MIDI cc, RPN/NRPN, GM 1&2 SysEx and even be assigned to individual MIDI channels.
MIDI cc (continuous controller) numbers are part of the standard MIDI specifications and are typically used to control the real-time changing of
parameters in musical equipment. For a complete list of standard MIDI controller numbers from 0 to 131, please see Appendix E on page XX.
Any of the 47 real-time controllers on the UC-33 can be assigned to a MIDI cc number however the 14 assignable buttons have slightly different options
from the 9 faders or 24 rotary controllers.
The following 2 charts show all the transmit messages you can program for each of the 33 fader/controllers and 14 assignable MIDI buttons respectively.
We show you this already at this stage, so you can follow the principle of programming the UC-33 controllers in the following instructions and
examples.
Please pay extra attention to the differences between how you program the faders or controllers and how you program the buttons.
Faders & Controllers Faders & Controllers
ASSIGN Description Data Lsb (Press Twice) Data Msb (Press Twice)
0-119 Standard MIDI CC’s - -
120-127 Channel Mode Messages - -
128 Pitch Bend Sensitivity - -
129 Channel Fine Tune - -
130 Channel Coarse Tune - -
131 Channel Pressure - -
132 RPN Coarse RPN LSB RPN MSB
133 RPN Fine RPN LSB RPN MSB
134 NRPN Coarse NRPN LSB NRPN MSB
135 NRPN Fine NRPN LSB NRPN MSB
136 Master Volume GM* Volume LSB Volume MSB
137 Master Pan* Pan LSB Pan MSB
138 Master Coarse Tune* Tuning LSB Tuning MSB
139 Master Fine Tune* Tuning LSB Tuning MSB
140 Chorus Mod rate** Mod rate -
141 Chorus Mod Depth** Mod depth -
142 Feedback** Feedback level -
143 Send to Reverb** Reverb send level -
144 Pitch Bend Pitch shift LSB Pitch shift MSB
255 Controller Off**** - -
* General MIDI SysEx messages - for details please see pages XXX & XXX.
** General MIDI 2 SysEx messages
*** MMC Sysex messages, for details please see page XXX.
**** This value cannot be typed in using the numerical keypad.
