GA-8N-SLI Quad Royal Post Code Definition 11/14/2005 1

GA-8N-SLI Quad Royal Post Code Definition

AWARD Post Code Definition

POST (hex) Description

CFh Test CMOS R/W functionality.

C0h Early chipset initialization:

-Disable shadow RAM

-Disable L2 cache (socket 7 or below)

-Program basic chipset registers

C1h 1. Detect memory

-Auto-detection of DRAM size, type and ECC.

-Auto-detection of L2 cache (socket 7 or below)

2. PEG slots Auto-Configuration

C3h Expand compressed BIOS code to DRAM

C5h Call chipset hook to copy BIOS back to E000 & F000 shadow

RAM.

0h1 Expand the Xgroup codes locating in physical address 1000:0

03h Initial Superio_Early_Init switch.

05h 1. Blank out screen

2. Clear CMOS error flag

07h 1. Clear 8042 interface

2. Initialize 8042 self-test

08h 1. Test special keyboard controller for Winbond 977 series Super

I/O chips.

2. Enable keyboard interface.

0Ah 1. Disable PS/2 mouse interface (optional).

2. Auto detect ports for keyboard & mouse followed by a port & interface swap

(optional).

3. Reset keyboard for Winbond 977 series Super I/O chips.

0Eh Test F000h segment shadow to see whether it is R/W-able or not. If

test fails, keep beeping the speaker.

10h Auto detect flash type to load appropriate flash R/W codes into the

run time area in F000 for ESCD & DMI support.

12h Use walking 1’s algorithm to check out interface in CMOS

circuitry. Also set real-time clock power status, and then check for

override.
