P-touch Template Command Reference

- 79 -

7. Control Command Details

ESC iXf1 Retrieve prefix character

ASCII: ESC i X f 1 n1 n2

Decimal: 27 105 88 102 49 nd1 nd2

Hexadecimal: 1B 69 58 66 31 nh1 nh2

Parameters

nh1: 00h (Fixed)

nh2: 00h (Fixed)

Description

 Retrieves the prefix character code.

 3-byte data is returned from the printer.

[1]:

01h (Fixed)

[2]:

00h (Fixed)

[3]:

Specified character

 The retrieved value is a value specified by a static command.

Example

 When the prefix character is set to “_”:

Code: ESC i X f 1 00h 00h

(1Bh 69h 58h 66h 31h 00h 00h)

Returned value: 01h 00h 5Fh (5Fh stands for “_” in ASCII code)
