GP40-II - деталировка
Руководство по эксплуатации Страница: 2

Champion GP40-II - деталировка Руководство по эксплуатации онлайн [2/3] 770656

Champion GP40-II - деталировка Руководство по эксплуатации онлайн [2/3] 770656

25 3C9501006

absorber

4

26 3S7106004

bearing 6004

2

27 3C9505003

valve base gasket

1

28 3S2506073

stub AM6×73

2

29 3C9505200

intake reed comp

1

30 3S22060201

bolt,flange M6×20

4

31 3C9505004

intake gasket

1

32 3C9505100

carburetor assembly

1

33 3C9505002

carburetor，plate B

1

34 3MGG950901

control panel assembly

1

35 3C9505001

carburetor，plate A

1

36 3C9504008

Air filter

1

37 3S12061

nut M6

2

38 3C9504006

control panel cover

1

39 3S29500151

Screw M5*15

4

40 3C9505011

spring,tension

1

41 3C9505010

rod,link

1

42 3C9505300

governor arm

1

43 3C9505009

spring,governor

1

44 3S5110014

pin 10×7×14

2

45 3S25060503

stud AM6×50

2

46 3C9501003

circlip

1

47 3C9503100A

crankshaft assembly

1

48 3S22060161 bolt M6×16 2

49 3S31061 spring washer Φ6 2

50 3S35061 plain washer Φ6 2

51 3C9503007

collar bush

1

52 3C9503300

weight comp

1

53 3C9503002

piston pin

1

54 3C9505006

governor fork

g

1

55 3S35032

plate washerΦ6

2

56 3S31032

spring washer Φ3

2

57 3S27030082

screw M3×8

2

58 3C9503005

piston

1

59 3C9502006

gasket,muffler

1

60 3C9502200P

muffler assembly

1

61 3S22060161 bolt,flange M6×16 2

62 3S22060201

Bolt M6*20

1

63 3C9505012

ignition coil assy seat

1

64 3S12061

Nut M6

1

65 3C9504400A

ignition coil assy

1

66 3S35061 washer,plate Φ6 2

67 3S1606118 nut M6 2

68 3C9504300

spark plug

1

69 3S22060121 bolt,flange M6×12 2

70 3C9505005

governor shaft

1

71 3S25061163

stud AM6×110

2

72 3S61061204

oil seal 6×12×4

1

73 3C9501001A

crankcase,rear

1

74 3S22060301

screw M6×30

2

75 3S31061 washer,spring Φ6 2

76 3S35061 washer Φ6 2

77 3C9506005A

handle

1

78 3C9506100S

fuel tank comp

1

79 3S22060161

Bolt M6*16

4

80 3C9506300

fuel tank cock assy

1

81 3C9506003

fuel pipe

1

82 3C9506004

pipe clip

2

83 3C9506200

cap assy

1

84 3C9506001

fuel cup

1

85 3C9506002

strainer

1

86 3G3040001

Pump cover

1

87 3G4050004

rubber washer

4

88

3S24080603

Inner hex bolt M8x60

4

89 3G3040003

O ring

1

90 3G3040006

porcelain seal

1

91 3G3040007

water

p

um

p

im

p

elle

r

1
