6. Технические характеристики.

6. TECHNICAL SPECIFICATIONS

AUDIO INPUT

Type Active balanced XLR and 1/4" JACK

Impedance Balanced: 50kOhm Unbalanced: 25kOhm

Operating level +4dBu/ 10dBV

Maximum input level Balanced and Unbalanced: +19dBm

CMRR >55dB @1kHz

AUDIO OUTPUT

Type XLR and 1/4" JACK

Impedance Balanced: 60Ohm Unbalanced: 30Ohm

Maximum output level +21dBm

SYSTEM SPECIFICATIONS

THD+N% 0.01% typ. 1kHz, @+4dBu

Noise >-92dBr unweighted 22Hz to 22kHz

Frequency response 10Hz to 30kHz, 3dB

Low cut filter Variable (15Hz to 360Hz)

High pass filter 40Hz

Low pass filter 16kHz

Notch 1 frequency 400 ~ 4kHz / 40 ~ 400Hz

Notch 2 frequency 200 ~ 2kHz / 2k ~ 20kHz

Notch depth Variable 0 ~ -20dB

Graphic EQ band separation 2/3 Octave. 1 15 band

INDICATORS

Output level 8-segment LED display:-24/-18/-12/-6//0//+6/+12/+18dB

Function switch LED indicator of every switch

POWER SUPPLY

Main voltages USA/Canada 95 -120V ~, 60Hz

Europe 210 -240V ~, 50Hz

U.K./Australia 240V ~, 50Hz

Power consumption

Fuse 95 -120V: T315mAL 250VAC

210-240V: T200mAL 250VAC

Main connection Standard IEC receptacle

PHYSICAL

Dimension 483(W) 194.1(D) 44(H)mm

Weight 2.8kg
