PRO MIXER VMX100

4. SPECIFICATIONS

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be

made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or

illustrated.

4. SPECIFICATIONS

AUDIO INPUTS

Mic input 53 dB gain, servo-balanced

Phono inputs 1 and 2 40 dB gain @ 1 kHz, unbalanced

Line inputs 1 and 2 0 dB gain, unbalanced

AUDIO OUTPUTS

Main Out max. +21 dBu @ +15 dBu (LINE IN)

Tape Out typically 0 dBu

Headphones typically 125mW @ 1 % THD

EQUALIZER

Stereo Low +12 dB/-32 dB @ 50 Hz

Stereo High +12 dB/-32 dB @ 10 kHz

GENERAL

Signal-to-noise ratio (S/N) > 88 dB (Line)

Crosstalk > 67 dB (Line)

Distortion (THD) < 0.025 %

Frequency response 20 Hz - 20 kHz

Input gain adjustment -20 dB - +9 dB

POWER SUPPLY

Mains voltages USA/Canada 120 V~, 60 Hz

Europe/U.K./Australia 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

General export model 120/230 V~, 50 - 60 Hz

Power consumption max. 10 W

Fuse 100 - 120 V~: T 160 mA H 250 V

200 - 240 V~: T 80 mA L 250 V

Mains connection Standard IEC receptacle

DIMENSIONS AND WEIGHT

Dimensions (H x W x D) approx. 2 7/8" (72 mm) x 8" (203 mm) x 9" (229 mm)

Weight approx. 2 kg
