3. Fix Ratio Button

You can fix the aspect ratio of the video window when resizing it using this button.

4. PIP (Picture In Picture) Button

You can set up PIP (Picture In Picture) using this button.

V Mute Button

Using this button, you can mute the audio of a call.

Once the AV Mute button is pressed, you can only use this button again after 3 seconds.

6. Size

Shows the resolution to be transmitted for the user you are talking with. (CIF/4CIF)

7. bps Configuration Tab

Shows the data transmission rate for the user you are talking with.

The bps configuration tab is only enabled 3 seconds after a user sets the bps.

8. Screen Name

Shows the screen name and IP address of the user you are talking with.

9. Mute Button

You can mute the sound from the monitor.

Once the Mute button is pressed, you can only use this button again after 3 seconds.

10.Volume Control Bar

You can control the volume of the monitor.

11.Current Time/Call Time

The time on the left is the current time and the time on the right is the elapsed time of the current

call.

Sendin

/Receivin

/Disconnectin

a Call

1. In the Phonebook screen, select and right-click the person to video call and select Call from the

displayed menu.

Sendin

a Call

Some Wa

s to Make a Video Call

1.In the Phonebook screen, double-click the person to video call.

In the Call history screen, double-click an entry of the person to video call, or right-click it
