Visit the MagicTune™ website and download the installation software for MagicTune™ MAC.
Check the followin
g
items if there is trouble with the monitor.
Symptom Solutions
The screen does
not appear when I
switch to the Client
Mode.
To use the network function, approximately 30 seconds of booting time is
required after turning the power on, and a blank screen appears for 3 to 4
seconds during booting.
Please switch the mode about 30 seconds after the power is turned on.
The client screen
appears, but I
cannot connect to
the server.
1) Check if the Hub port LED to which the LAN cable is connected blinks. If not,
that indicates that the LAN connection is disconnected. In this case, connect
using another LAN cable.
2) Check if the settings of the 'Settings', 'Network' tab are properly set up. The
default setting is "DHCP". If your network uses a static IP address, select 'Use
the following IP address' and then enter the appropriate IP address information.
3) Check if the 'User Name' and 'Password' set in the 'Remote Desktop' tab of
'Settings' are the same as those of the host PC. If not, match the 'User Name'
and 'Password' of the 'Remote Desktop' with those of the host PC.
I cannot access the 1) Check if the Hub port LED to which the LAN cable is connected blinks. If not,
with Window OS
that supports Plug
and Play.
Control Panel → Performance and Maintenance →
System → Hardware → Device Manager → Monitors →
After deleting Plug and Play monitor, find 'Plug and Play
monitor' by searching new Hardware.
MagicTune™ is an additional software for the monitor.
Some graphic cards may not support your monitor.
When you have a problem with the graphic card, visit
our website to check the compatible graphic card list
provided.
http://www.samsung.com/monitor/magictune
MagicTune™
doesn't work
properly.
Have you changed
your PC or video
graphic card?
Did you install the
program?
Download the latest program. The program can be
downloaded
http://www.samsung.com/monitor/magictune
Reboot the computer after installing the program for the
first time. If a copy of the program is already installed,
remove it, reboot the computer, and then install the
program again. You need to reboot the computer for it
to operate normally after installing or removing the
program.
Problems related to
Audio
No sound Ensure that the audio cable is firmly connected to both
the audio-in port on your monitor and the audio-out port
on your sound card.
(Refer to Connecting the Monitor)
Check the volume level.
Sound level is too
low.
Check the volume level.
If the volume is still too low after turning the control to its
maximum, check the volume control on the computer
sound card or software program.
I pressed the Power
button to turn the
monitor off. But only
the message 'Please
Wait' appears and
the monitor does not
turn off even after a
lot of time has
passed.
Please shut down
the monitor
forcefully.
Windows XPe may sometimes not shut down normally.
In this case, please shut the monitor down by force by
holding down the Power Button for five (5) seconds.
