C. OPERATION:

After power on, Press “MODE”button to activate the main menu: Built-in program, Auto run, DMX mode, Slave

mode, sound mode.

Built-in programs-- running one of 17 built-in programs

Auto run—running built-in programs one after another in continuous loop.

DMX mode--controlled by DMX controller

Slave mode—the projectors in this mode will be synchronously run with the projectors in master mode

Sound mode-- running by sound - activated

1. built-in programs

one program is a sequence of different steps, with Led dance floor 100x100cm yon can select 17 different Programs.

press“set up”and up/down buttons to select the programs (Pr. 01-Pr. 17) and select the desired program value (step

time, flash, Pr. 14-Pr. 17- Fade time)

For example,

Press “setup”button to move the cursor to select 02 and the desired Sp (step time)or Fs (flash speed)

Sp--step time value from 01-Full (100)

Fs--flash speed from 00-99

Fd—Fade time value from 00-99

2. Auto run mode

Running 15programs in a continuous loop, the frequency means the running times. it can be set up via the buttons

up/down

3. DMX mode

You can control the devices individually via your DMX-controller

1) Addressing

The control Board allows you to assign the DMX address which is defined as the first channel from which the Led

dance floor 100x100cm will respond the controller. For address setting, press “set up”buttons until the display shows

as follows: d.001~d.512

Set the desired address via the up/down buttons

2) DMX-PROTOCOL

The control Board allows you to set 1,2,3,4,5,6,7 DMX channel for different applications.

press“set up”button until the display is as follows: d-P1~d-P7

 set mode :01

CH.1 CH.2 CH.3

RED GREEN BLUE

0-255 0-255 0-255

O=OFF O=OFF O=OFF
