DYNAMIC MICROPHONE XM1800S

6. SPECIFICATIONS

4. HOW TO USE YOUR XM1800S MOST EFFECTIVELY

Adjust the gain control in the microphone channel of your mixing console so that the peak LED lights

up only occasionally or never at all. The EQ controls in the microphone channel should be set to

mid-travel position to start with; low-cut filter and level attenuator should be turned off. Try to achieve

the desired sound by experimenting with the microphone position. Place the microphone as close to

the sound source as possible. The closer your mic gets to the sound source, the greater the bass

response will be. On the other hand, as you move the sound source further away from the microphone,

the bass response will gradually roll off (please see frequency response chart on next page).

Only when the desired basic sound has been achieved, should you start to use equalizers and

signal processors, if any at all. (Remember: less is often more!)

All microphones have characteristic polar patterns that determine how well signals from around the

area of the microphone are accepted or rejected.

The super cardioid pattern is used by the XM1800S. Thus, the XM1800S excels in environments

where a lot of undesired ambient noise exists. The XM1800S excellently reproduces those sound

signals originated directly in front of the microphone while rejecting or minimizing sound signals

originated in the area behind the microphone (please refer to the polar pattern on next page for

detailed information).

5. WARRANTY

+ Please find our current warranty terms on our web site under http://www.behringer.com

or send us a request by e-mail (support@behringer.de), fax (+49 2154 9206 4199), or

telephone (+49 2154 9206 4166).

6. SPECIFICATIONS

Type: Dynamic

Frequency response: 80 Hz - 15 kHz

Polar pattern: Super cardioid

Impedance: 600 Ω

Sensitivity: -52 dBV (0 dBV = 1 V/Pa), 2.5 mV/Pa

Connector: 3-pin balanced XLR (male)

Dimensions:

Head length 57.5 mm

Main unit length 117.5 mm

Total length 175 mm

Weight: 230 g
