EN EXTERIOR (see fig. A on p. 2)

① – volume control wheel; ② – mute button; ③ – LED indicator; ④ – multifunction button;

⑤ – USB Type-C connector; ⑥ – 3.5 mm AUX connector; ⑦ – microphone.

SPECIFICATIONS

Purpose: the Lorgar Noah 501 wireless headset is designed to play audio from computers,

gaming and mobile devices with BT and voice calls functions.

Design features: 195×185×80 mm; ABS plastic, polyurethane; retractable microphone,

volume control.

Functional features. Connection: BT (5.3, up to 10 m, 10 dBm, 0.01 W), 3.5 mm AUX cable.

Battery: non-removable, lithium polymer, 1000 mAh (power supply output: 5 V / 1 A DC);

≥300 recharge cycles; full charge: 2 hours. Autonomous work: up to 58 hours. Standby mode:

up to 200 hours. Microphone: omnidirectional, (−42 ± 3) dB. Speakers: 40 mm, (123 ± 3) dB,

20–20000 Hz, 32 Ohms. Operating and storage conditions: temperature +10...+45 °C,

relative humidity 45–85 % (non-condensing).

Accessories: Headset LRG-GHS501, USB Type-C Cable (0.8 m), AUX cable 3.5 mm

(1.5 m), quick start guide.

SAFE USE GUIDELINES

Before using the headset, set the minimum volume on your device * to avoid hearing damage.

Do not use the headset while driving a vehicle. Do not expose to high temperatures (from

heaters or direct sunlight) or high humidity. Avoid dust or liquids. Clean only after

disconnecting from the power supply and with a dry or slightly damp cloth only. Do not use

any detergents or cleaning agents. Don't let it fall from a height. Do not disassemble or repair

the headset by yourself. If there are any malfunctions, please contact the service center.

GETTING STARTED

1. Charging. Before the first use, fully charge the battery (see Fig. B on p. 2). While charging,

the LED indicator ③ lights red; when fully charged, it goes off and the headset

stops charging.

2. Turning on. Press and hold the button ④ for 3 seconds until the LED indicator ③ flashes red

and blue. When wired, the headset works without turning on (see fig. C on p. 3).

3. Pairing. Turn on BT on your device *, locate and select “Lorgar Noah 501” for pairing. To

delete the pairing information, hold down the buttons ④ and ② simultaneously for 3 seconds.

4. Turning off. Press and hold the button ④ for 2 seconds, the LED indicator ③ will light red

and go off.

5. Other features of the buttons: see Fig. D on p. 3.

WARRANTY SERVICE

The warranty period begins on the date of purchase from an authorized Lorgar retailer. To

obtain warranty service, visit the point of purchase, presenting the device and proof of

payment. The warranty is 2 years, unless otherwise specified by local law. The service life is

2 years. More information about use and warranty is available at lorgar.eu/warranty-terms.

FURTHER INFORMATION.

We hereby reserve the right to change the information contained herein without noticing the

end users. Please find up-to-date information and a detailed description hereof, connection

and operation steps, certificates, warranty conditions in the complete user manual at

lorgar.eu/drivers-and-manuals. Manufacturer: ASBISc Enterprises PLC, Iapetou, 1, Agios

Athanasios, 4101 Limassol, Cyprus. Made in China. All trademarks and brand names are the

property of their respective owners.

* Device means a computer, a laptop, a tablet, a smart TV, etc.
