When there is a "fault code visible" type of fault or when the door is opened for a long

time, the light bar is flashing red.

Lock/unlock

In the non locked state, press and hold the "TEMP SELECT" for 3 seconds to enter the

locking state.

The unlock icon goes out and the lock buzzer sounds.

In the locked state, press and hold the "TEMP SELECT" for 3 seconds to enter the non

locking state.

The unlock icon lights up, the blue light bar lights up from the central axis to both

sides, and the unlocking beep sounds.

After 30 seconds of no operation, it will automatically enter the locking state, and the

lock buzzer will sound at the same time.

In addition to the alarm tone release operation can also be carried out in the locked

state, other operations must be carried out in the non locked state.

If it is operated in the locked state, an error beep will be given.

The light bar is in blue flashing state when the error is prompted.

Temperature setting

Temperature setting of refrigerating chamber

Press the "TEMP SELECT" to select the refrigeration temperature zone, and then press

the "+" and "-" button to adjust the temperature of the refrigerating chamber. Each

time the"-" key is pressed, the temperature will drop by 1°C, when the temperature

reaches 2°C, press the "-" button again will set the refrigeration chamber at 8°C; press

the "+" button once, the temperature will increase by 1°C, and press the "+" button

again when the temperature reaches 8°C will set the refrigeration chamber at 2°C.

The setting range of the refrigerating chamber is 2 ~ 8°C;

The setting will take effect after locking.

Setting of variable chamber

Press the "TEMP SELECT" to select the temperature zone of the variable chamber, and

then press the "+" "-" button to adjust the variable chamber. Each time the"+" key is

pressed, it shifts up once; Each time the "-" key is pressed, it will switch downward

once; cycle according to the following way:

VEG. - FRUITS - > ZERO FRESH - > FISH - MEAT - > VEG. - FRUITS.

After locking the establishment takes effect.

Temperature setting of freezing chamber

Press the "TEMP SELECT" to select the freezing chamber, and then press the "+" and "-"

keys to adjust the temperature of the freezing chamber.

Each time the "-" key is pressed, the temperature drops by 1°C.

When the temperature reaches - 24°C, press the "+" button once again, the freezing

chamber is set to -16°C; each time the "+" button is pressed once, the temperature

increases by 1°C; when the temperature reaches -16°C, press the "+" button again, the

freezing chamber will set to - 24°C. The setting range of cold storage room is -16 ~

-24°C, the setting will take effect after locking.
