IM2022

8. OPERATION OF THE DEVICE

Fig. 2*

*The appearance of the control panel may differ from the images in the manual

Operating mode selection knob

Used to select the following operating modes: ventilation mode , heating mode

Thermostat knob

Used to set the room heating temperature

Operation of the fan heater

1. Turning on

Make sure that the operating mode selection knob is set to position, then connect the device to the

power source and set the operating mode selection knob to position, the electric motor of the device will

turn on and the device will start operating in ventilation mode.

2. Heating power selection

2.1. Set the operating mode selection knob to position to select heating mode.

3. Temperature setting

3.1. The room temperature can be set in the range from 0 to +40 °C.

3.2. In heating mode, turn the thermostat knob fully clockwise, if the room temperature is lower than the set

temperature, the heating elements will turn on. When the room temperature reaches the desired level, turn

the thermostat knob counterclockwise until the heating elements turn off.

Now the thermostat will maintain the set temperature automatically, by turning on and off the heating

elements, the motor will work.

ATTENTION!

1. The first time the device is turned on, a specific odor and smoke may appear (oil is burned from the

surface of the heating elements). It is recommended to turn on the curtain in heating mode for 10-20 minutes

in a well-ventilated area.

2. After transportation or storage of the device at below 0

C temperatures, it is necessary to store it in the

room where operation is supposed to be, without turning the device on for at least 2 hours.

After prolonged storage or break in use, do not turn on the device in high heating power mode.

ATTENTION!

Frequent triggering of the emergency shutdown device is not normal mode of operation of the device. In this

case make sure that the device is really defective and contact an authorized service center.
