8 EN

• Check the delivery set.

• Examine the unit for damages, in case of damage do

not plug it into the mains.

• Make sure that specied specications of power supply

voltage of the unit correspond to the specications of

your mains. When using the unit in the mains with 60

Hz frequency, the unit does not need any additional

settings.

• Wipe the fan body with a slightly damp cloth and then

wipe it dry.

FAN ASSEMBLY

• Unscrew the base lock (14) from the stand (2) by

rotating it counterclockwise (pic. 1).

• nstall the base (1) on the stand (2), install the at

washer (13), screw the base lock (14) along the

thread, rotating it clockwise (pic. 2).

• Unscrew the fan clamp (12) not completely by rotating

it counterclockwise (pic. 3).

• Mount the fan body (11) onto the stand (2), screw

in the fan clamp (12) by rotating it clockwise. When

screwing the clamp (12) do not apply too much e󰀨ort

(pic. 3).

• Unscrew the blade lock (5) by turning it clockwise.

Unscrew the rear grid fastening nut (7) by turning it

counterclockwise (pic. 4)

• Match the guides on the motor unit with the

corresponding openings on the grid (8) and install the

rear grid (8) on the motor unit, x it with the nut (7),

turning it clockwise along the thread (pic. 5, 6).

• Install the blades (6) on the electric motor axis (9), and

x them with the lock (5), turning it counterclockwise

along the thread, hold the blades (6) with your free

hand (pic. 7, 8).

• Open the grid clamps, match the front (4) and rear (8)

grids, close the clamps, make sure that the grids (4

and 8) are properly xed (pic. 9, 10).

• Unscrew the xing screw at the bottom part of the grid

(pic. 11), set the clamp to the correct position (pic. 12),

tighten the xing screw (pic. 13).

Remote control (21)

• Before using the remote control (RC) (21) open

the battery compartment lid (27) and insert 2 «AA»

batteries (supplied with the unit) into the battery

compartment strictly following the polarity, close the

battery compartment lid (27).

Note: if there is an isolating insert in the battery

compartment, remove it.

• If you are not going to use the remote control for a long

time, open the lid (27) and remove the batteries from

the remote control (21) battery compartment.

• Battery leakage may cause injury or damage to the

remote control (21), to prevent damage to the remote

control (21), follow the instructions below:

- use only the «AA» batteries;

- do not use old and new batteries at the same time;

- do not recharge the batteries;
