Chapter 14 Bandwidth Control

GS2200-8/24 User’s Guide

130

14.2 Bandwidth Control Setup

Click Advanced Application > Bandwidth Control in the navigation panel to bring up the screen

as shown next.

Figure 82 Advanced Application > Bandwidth Control

The following table describes the related labels in this screen.

Table 37 Advanced Application > Bandwidth Control

LABEL DESCRIPTION

Active Select this check box to enable bandwidth control on the Switch.

Port This field displays the port number.

* Settings in this row apply to all ports.

Use this row only if you want to make some settings the same for all ports. Use this row first to

set the common settings and then make adjustments on a port-by-port basis.

Note: Changes in this row are copied to all the ports as soon as you make them.

Active Select this check box to activate ingress rate limits on this port.

Ingress

Rate

Specify the maximum bandwidth allowed in kilobits per second (Kbps) for the incoming traffic

flow on a port.

Note: Ingress rate bandwidth control applies to layer 2 traffic only.

Active Select this check box to activate egress rate limits on this port.

Egress

Rate

Specify the maximum bandwidth allowed in kilobits per second (Kbps) for the out-going traffic

flow on a port.
