Chapter 17 Link Aggregation

GS2200-8/24 User’s Guide

138

is, if an operational port fails, then one of the “standby” ports become operational without user

intervention. Please note that:

• You must connect all ports point-to-point to the same Ethernet switch and configure the ports for

LACP trunking.

• LACP only works on full-duplex links.

• All ports in the same trunk group must have the same media type, speed, duplex mode and flow

control settings.

Configure trunk groups or LACP before you connect the Ethernet switch to avoid causing network

topology loops.

Link Aggregation ID

LACP aggregation ID consists of the following information

17.2 Link Aggregation Status

Click Advanced Application > Link Aggregation in the navigation panel. The Link Aggregation

Status screen displays by default. See Section 17.1 on page 137 for more information.

Figure 85 Advanced Application > Link Aggregation Status

Table 40 Link Aggregation ID: Local Switch

SYSTEM PRIORITY MAC ADDRESS KEY PORT PRIORITY PORT NUMBER

0000 00-00-00-00-00-00 0000 00 0000

Table 41 Link Aggregation ID: Peer Switch

SYSTEM PRIORITY MAC ADDRESS KEY PORT PRIORITY PORT NUMBER

0000 00-00-00-00-00-00 0000 00 0000

1. Port Priority and Port Number are 0 as it is the aggregator ID for the trunk group, not the individual port.
