Chapter 18 Port Authentication

GS2200-8/24 User’s Guide

147

18.3 Activate IEEE 802.1x Security

Use this screen to activate IEEE 802.1x security. In the Port Authentication screen click 802.1x

to display the configuration screen as shown.

Figure 92 Advanced Application > Port Authentication > 802.1x

The following table describes the labels in this screen.

Table 45 Advanced Application > Port Authentication > 802.1x

LABEL DESCRIPTION

Active Select this check box to permit 802.1x authentication on the Switch.

Note: You must first enable 802.1x authentication on the Switch before configuring it on each

port.

Port This field displays the port number.

* Settings in this row apply to all ports.

Use this row only if you want to make some settings the same for all ports. Use this row

first to set the common settings and then make adjustments on a port-by-port basis.

Note: Changes in this row are copied to all the ports as soon as you make them.

Active Select this to permit 802.1x authentication on this port. You must first allow 802.1x

authentication on the Switch before configuring it on each port.

Max-Req Specify the number of times the Switch tries to authenticate client(s) before sending

unresponsive ports to the Guest VLAN.

This is set to 2 by default. That is, the Switch attempts to authenticate a client twice. If the

client does not respond to the first authentication request, the Switch tries again. If the

client still does not respond to the second request, the Switch blocks the client from

accessing the port or sends the client to the Guest VLAN when a Guest VLAN is enabled on

the port. The client needs to send a new request to be authenticated by the Switch again.
